SPI LED Controller KIT

 390.0  290.0 excl. VAT

Smallest stand-alone digital LED controller. A single device can handle 1024 RGB or 768 RGBW pixels.



Demo KIT contains

  • SPI LED Controller
  • LED Strip Studio software lite license + prepared workspace with scenes and proper mapping for 1 roll of LED strips
  • 1 x 5 meter of PRO 42/m LED pixel strip
  • Prepared cables & wires
  • SD-card + adapter
  • Power supply



Effects and shows can be created in our LED Strip Studio Software and easily uploaded to Micro SD card. Store up to 255 effects and trigger them using hardware buttons or DMX.

7 in stock

Description

Description



PI LED Controller supports most common connectors such as 2 x RJ-45 and one SPI connector (2EDGK) for your LEDs. You can also find a slot for SD-Card and buttons for control in stand-alone mode.



SPI LED Controller offers several DMX modes



1. DMX pixel mode, where each LED pixel can be created with one or several LEDs.

2. DMX Trigger mode (SD-Card), where you can use DMX as trigger stored animations on SD-Card.



SPI LED Controller to use RJ-45 connectors as DMX in and DMX out. Complete scheme how to make an adapter from RJ-45 to 3 pin XLR in/out you can find in the user manual.

Technical specification

Additional information

Weight 300 g
Dimensions 90 × 60 × 110 mm
Maximum of LEDs

1024

SPI LED Outputs

1

Maximum of LEDs per Output

1024

Required power

5-24V/ 0.3A (PCB only, wihout the LED strips / LED pixels)

Pass-Thru Current

10A

Power connector

pluggable terminal block with 5 mm contact spacing e.g. SH04-5-GY

SPI OUT connector

pluggable terminal block with 5 mm contact spacing e.g. SH04-5-GY

DMX input connector

RJ-45

DMX output connector

RJ-45

SD Card

Micro SD Card (FAT32, up to 32GB)

Documentation

https://www.ledstripstudio.com/download/tech-specs/SPI_LED_Controller_tech_specs.pdf

Tutorials

https://ledstripstudio.com/tutorials/spi-led-controller-tutorial/
